Dettagli:
|
| warranty: | 1 year | customized support: | OEM, ODM |
|---|---|---|---|
| application: | Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, HVAC OEM, Industrial Boilers, Industrial Utilities, Irrigation and Ag | power source: | Pneumatic |
| pressure: | Low Pressure | structure: | Diaphragm Pump |
| outlet size: | 3 inch | voltage: | NO |
| power: | NO | motor: | NO |
| Material: | Ductile Iron | Name: | AODD Pump |
| Color: | black | Weight: | 100kgs |
| Diaphragm: | PTFE | Brand: | RV |
| Packing: | carton | Max pressure: | 120psi(0.84Mpa,8.4bar) |
| Pump body: | Ductile Iron | Max Flow: | 270gpm(1022lpm) |
| Evidenziare: | pompa a membrana in plastica per acque reflue,pompa a membrana per irrigazione agricola,pompa a membrana industriale con garanzia |
||
Pressione di lavoro massima | 120 psi (0,84Mpa, 8,4bar) |
Tasso di flusso massimo | 270 gpm ((1022Lpm) |
Velocità massima reciproca | 135cpm |
Altezza massima di aspirazione (aspirazione a secco) | 5 metri |
Grano massimo consentito | 0.37in. (9.4mm) |
Consumo massimo di aria | (90L/S) |
Dimensione dell'entrata d'aria | 3/4 in |
Dimensione della presa d'aria | 1 in |
Dimensione dell'entrata del fluido | 3 in |
Dimensione dell'uscita del liquido | 3 in |
Peso | Aluminio 99,5 kg Ferro duttile 200 kg |
