Dettagli:
|
| warranty: | 1 year | customized support: | OEM, ODM |
|---|---|---|---|
| application: | Other, Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, HVAC OEM, Industrial Boilers, Industrial Utilities, Irrigation and Ag | power source: | Pneumatic |
| pressure: | Low Pressure | structure: | Diaphragm Pump |
| outlet size: | 1inch | voltage: | Pneumatic |
| power: | no | motor: | no |
| Material: | SST | Name: | AODD Pump |
| Color: | black | Weight: | 66kgs |
| Diaphragm: | PTFE | Brand: | RV |
| Packing: | Wooden Case | Max pressure: | 120psi(0.84Mpa,8.4bar) |
| Pump body: | SST | Max Flow: | 150gpm(570lpm) |
| Evidenziare: | Pompa sanitaria a doppio diaframma in PTFE,Pompa pneumatica per latte acido,Pompa a diaframma per il trattamento delle acque reflue |
||
Pressione di lavoro massima | 120 psi (0,84Mpa, 8,4bar) |
Tasso di flusso massimo | 40 gpm ((150lpm) |
Velocità massima reciproca | 276cpm |
Altezza massima di aspirazione (aspirazione a secco) | 5 metri |
Grano massimo consentito | 0.16 in (4 mm) |
Consumo massimo di aria | 45 scfm ((22,5 L/S) |
Dimensione dell'entrata d'aria | 1/2 pollice |
Dimensione della presa d'aria | 3/4 in |
Dimensione dell'entrata del fluido | 1 in |
Dimensione dell'uscita del liquido | 1 in |
Peso | Peso della pompa: 34 kg |
